Steel frame assembled from 3 drawings with NVIDIA CAD

Construction AI consultant Akihiro Nitta fed three structural drawings to AI, which identified 74 steel members, created each to exact dimensions in NVIDIA's free CAD engine, added six equipment holes, and calculated a weight of 36.1 tonnes.

View on X
333likes
34reposts
309saves
23Kviews
Made with
NVIDIA CAD engine
Role
Construction AI consultant
Posted
新田あきひろ｜建設業特化AI×BPOのツクノビ代表@akionionio

NVIDIAが無料公開したCADのエンジンで、鉄骨を組んでみた。
構造図3枚をAIに読ませて74本を拾い、1本ずつ寸法どおりの立体に。設備の穴も6か所あけて、重さは立体から36.1t。
同じφ175の穴でも、梁せい450の梁だけ目安オーバーになった。

View on X
Still from the video
